Steel billet electric induction heating equipment is a device that uses the principle of electromagnetic induction to heat steel billets. This heating method can improve production efficiency, reduce energy consumption, and has advantages such as uniform heating and precise temperature control.
Classification of electric Billet induction heating furnace :
1. Frequency classification:
-Intermediate frequency inductive heating equipment: operating frequency between 1 kHz and 20 kHz.
-High frequency inductive heating equipment: operating frequency above 20 kHz.
2. Classification of equipment structure:
-Coil type inductive heating equipment
-Flat panel inductive heating equipment
-Loop Induction Heating Equipment
Working principle of electric induction heating equipment for steel billets: The working principle of electric induction heating equipment for steel billets is based on Faraday’s law of electromagnetic induction. By placing an electromagnetic induction coil around the steel billet, the changing magnetic field generated when this coil is energized will induce eddy currents inside the steel billet, causing it to heat up. During the heating process, the resistance of the steel billet itself can convert electrical energy into thermal energy, causing the billet to heat up.
Application of electric steel billet induction reheating furnace :
1. Steel industry: mainly used for uniform heating of steel billets, such as forging, heat treatment and other processes.
2. Metal processing industry: suitable for heating treatment of metal materials, such as quenching, tempering, etc.
3. Automotive manufacturing industry: used for heating treatment of engine components to improve their strength and hardness.
Operation of electric induction heating equipment for steel billets:
1. Device startup: Start the power supply and ensure that the device is connected properly.
2. Temperature control: Set appropriate temperature and heating time according to the heating process requirements.
3. Safe operation: Follow the steel billet heating furnace operation manual to ensure safe operation procedures.
