Steel pipe induction hardening production line -China manufacturer

Steel pipe hardening furnace is a specialized induction heating heat treatment equipment designed and manufactured for steel pipes. By using a medium frequency furnace for heating, the heating speed has been improved, and online heating and hardening have been achieved. Combined with automatic control, the intelligence level of the steel pipe quenching furnace has been greatly upgraded, which meets the current automatic production requirements of intelligent factories.

Composition of Pipe induction hardening equipment :

The steel pipe hardening furnace is composed of IGBT energy-saving power supply, induction heating system, hardening spray system, conveying device, upper and lower pressure roller device, water spray cooling device, water tank, discharge mechanism, temperature measurement mechanism, Siemens PLC control, cooling device, etc.

The characteristics of Steel pipe hardening equipment :

1. The steel pipe hardening furnace has a wide range of applications: the diameter of the steel pipe is ø 50- ø 350, and the length is over 2.2m

2. Flexible heating of steel pipe hardening furnace: Sensors can be customized and designed according to needs to adapt to induction furnace bodies of different workpiece sizes. The furnace body temperature is controllable, energy-saving and efficient, and the speed is fast.

3. Equipped with “intermittent hardening” function, with a control error of no more than 5mm.

4. The mechanical strength and reliability of the steel pipe hardening furnace are reliable. The storage platform is welded with thick walled square pipes, with a slope of 13 degrees, and can store 10-50 pieces of material.

5. Intelligent PLC control, with a specially customized human-machine interface, user-friendly operation instructions, remote operation console with touch screen system, “one click restore” system, and multiple language switching functions.

6. It has good heat permeability, fast heating speed, energy conservation and consumption reduction, and a clean and tidy environment.
